Performance Data
| Pump Set Model | Voltage | Power (W) | Max.Flow (m³/hr) | Max.Head (m) | Delivery Size in mm |
| TS100-4/3000-SP | 300 | 3000 | 4.0 | 200 | 32/88 |
| TS100-8/2200-SP | 300 | 2200 | 8.0 | 100 | 32/88 |
Performance Curve
Compliance
| Nominal Dia | 100mm (4”) |
| Outer diameter | 100mm |
| Power Range | 2200-3000W |
| Voltage | 300 V. D.C. |
| Max. Head | 200m |
| Max. Discharge | 8m³/hr |
| Max.Immersion Depth | 30m |
| Motor | Oil filled DC motor |
| Impeller | Centrifugal |
| Outlet Size in mm | 32 / 38 |
Constructional Data
| Outlet | AISI / Brass |
| Pump Outer shell | AISI |
| Motor Outer Shell | AISI |
| Impeller | Noryl |
| Bearing | Ball Bearing |
